Working Environment
a) Ambient Temperature: +10℃ ~ +30℃.
b) Relative Humidity: ≤85%, non-condensing.
c) Atmospheric Pressure: 700hPa ~ 1060hPa.
d) Power Supply Requirements: AC 230V, 50Hz.
Input Power: 3600VA

​

Laser Beam Specifications
Mode and Wavelength
Mode：Multi-mode.
Wavelength： 808nm ± 10nm.

Spot Size: 18mm × 10mm

​

 Temporal Characteristics and Output Mode
Pulse Width: 5ms ~ 90ms
Frequency (Repetition Rate): 1Hz ~ 10Hz
Output Mode: Repetitive pulsed output.

Terminal Output Laser Energy Density
Maximum Laser Energy Density: 60J/cm²

​
